Rear Pair Air Suspension Bags For Ford Expedition Lincoln Navigator 1997-2002
Fitment:
- Ford | Expedition | 1997~2002 | 4.6L/5.4L
- Lincoln | Navigator | 1998~2002 | 5.4L
Item Specifications
Key Words: Rear Pair Air Suspension Spring Bags For 1997-2002 UN93 Ford Expedition, 1998-2002 UN173 Lincoln Navigator
Product Specifics
- Part Type: Air Suspension Spring
- Fitment Type: Direct Replacement
- Size: Single Dimension(CM) 38.00(Length)*18.00(Width)*18.00(Height)
- Single Weight(KG): 1.570
- Upper Mounting Isolator Included: No Isolator Required
- Lower Mounting Isolator Included: No Isolator Required
- Upper Mount Type: Base Cup
- Lower Mount Type: Base Cup
- Included Hardware: Mounting Hardware
- Drive Layout: Front Engine RWD/2WD
- Platform: UN173 UN93
- Custom Bundle: Yes
- Material: Iron,Aluminium Alloy,Rubber
- Quantity: Pair
- Warranty: 1 Year
- OE Spec or Performance/Custom: OE Spec
- Adjustable: Yes
- Greasable or Sealed: Sealed
- Brand: Only For Auto
- UPC: Does not apply
- Manufacturer Part Number: E805132CP01
- Interchange Part Number: Air Suspension Spring Bags, Air Ride Spring Bags
- Other Part Number: 3U2Z5580KA, 3U2Z5580AA
- Superseded Part Number: 3U2Z5580BA
- *Platform Drive Layout: Front Engine-Rear Wheel Drive Layout
-
*OEM Part Number:
3U2Z5580KA,3U2Z5580AA,
3U2Z5580BA,3U2Z5580PA
*Removal Guideline
CAUTION: Damage to the vehicle and air suspension system can be incurred if work is carried out in a manner other than specified in the instructions or in a different sequence.
To avoid the possibility of short circuits while working with electric components consult your owner's manual on how to disconnect your battery.
Consult your vehicle owner's manual, service manual, or car dealer for the correct jacking points on your vehicle and for additional care, safety and maintenance instructions. Under no circumstances should any work be completed underneath the vehicle if it is not adequately supported, as serious injuries and death can occur.
Removal Guideline
1.Set steering to straight ahead.
2.Raise vehicle.
3.Remove rear wheel.
4.Remove air spring solenoid retaining-clip.
5.Rotate solenoid counterclockwise to the first stop, and then carefully pull out to vent the air pressure from the air spring. After air spring is deflated, turn again and remove solenoid from air spring.
6.With pliers, or a suitable hooked tool, remove the clip that secures the top of the air spring to the chassis. Note: to access the clip, go under the wheel arch, between the body of the vehicle and the chassis.
7.Remove the piston-to-axle spring seat clip. (Air spring is held in place with a round retainer clip under the piston cap. To unsnap clip, gently pry between the piston and the axle. Clip will unsnap when pressure is applied.)
8.Carefully remove air spring from the vehicle.
Seal off solenoid to prevent any dirt or grease from entering system.
*Installation Guideline
Installation is in the reverse order of air spring removal. Use supplied o-rings for the air spring solenoid.
*Removal Warning & Notice
Note
The vehicle must be positioned on a suitable lifting device prior to deflating the air suspension system.
With the vehicle in NEUTRAL, position on a hoist until the wheel and tire assemblies are slightly above the ground.
2.Using the scan tool, vent the air springs.
3.Remove the air spring retainer.
4.Detach the air spring from the rear axle.
5.Remove the air spring in the following sequence.
1.Disconnect the air spring solenoid electrical connector.
2.Compress the quick connect locking ring and pull out the air tube.
3.Remove the air spring.
Includes
Pair for Rear Left & Right Air Suspension Spring Bags
Notes : Please double confirm the compatibility as well as the OEM number before purchasing.
Instruction is not included. Professional installation is recommended.
